ODIN Intercom Matrix Menu System Description 109
To Frame Field
The To Frame field displays the number of the frame connected to the Primary/Secondary Uplink/Downlink connector on the
current frame.
Tx Messages Field
The Tx Messages field displays the number of messages sent from the ODIN frame.
To Link Field
The To Link field displays the physical connection to which the frame is connected. For example, the Primary Uplink connector of
the current frame would show it being connected to the Primary Downlink of the next frame in the system.
Rx Messages Field
The Rx Messages field displays the number of messages received.
IP Address Field
The IP Address field displays the IP address of the frame being linked to.
Rx Errors Field
The Rx Errors field displays the number of errors received.
SFP Installed Field
The SFP Installed field displays whether or not an SFP module is installed in the frame.
Available statuses are:
SFP Tx Fault Field
The SFP Tx Fault field displays if a fault has occurred on the link.
Tx Power Field
The Tx Power field displays the amount of power used to transmit the outgoing fiber signal.
Rx Power Field
The Rx Power field displays the amount of power being received from the incoming fiber signal.
SFP is installed.
No SFP is installed.
