86 Menu System Description ODIN Intercom Matrix
Link Up Field
The Link Up field displays status of the fiber link.
Available statuses are:
Speed Field
The Speed field displays the transmission speed over the OMNEO interface.
The OMNEO interfaces support 100 Mbps and 1 Gbps.
Duplex Field
The Duplex field displays the transmit mode the OMNEO network interface is currently operating – Half or Full Duplex. Almost
all Ethernet interfaces auto-negotiate to Full Duplex. If the interface displays Half Duplex mode, this typically signifies the auto-
negotiate failed, resulting in network collisions and errors.
Available options for this field are
Half-Duplex – can either transmit or receive, but not both simultaneously.
Full-Duplex – can transmit and receive simultaneously.
SFP Installed Field
The SFP Installed field displays whether or not the transceiver module is installed on ODIN. This field is directly tied to the Link
Up field. If a transceiver module is not installed the OMNEO (SFP) port cannot be used.
SFP Tx Fault Field
The SFP Tx Fault field displays if a fault has occurred.
Tx Power Field
The Tx Power field displays the amount of power used to transmit the outgoing fiber signal.
Rx Power field
The Rx Power field displays the amount of power being received from the incoming fiber signal.
The fiber module is installed and the link is connected.
The fiber module is installed, but the link is not connected.
The fiber module is not installed.
An error has occurred. While this field is highlighted, press the SEL button to display a fault description.
No errors detected.
