SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 900109
Rev. A
6-24
Section 6. Replacement Procedures
STEP PROCEDURE
1. Switch the printer OFF and disconnect the power cord.
2. Unfasten (5) screws from the left side cover and remove.
3. Remove (1) Item 3 screw to detach Item 5 Sensor.
4. Detach Item 4 connector.
5. Remove and replace the sensor.
6. Reattach Item 4 connector.
7. Replace the left side cover.
8. Refer to Section 4.13 “Checking the Ribbon Sensor”.
6.17 Replacing the Ribbon Sensor (CSEN PCB) TT Unit
REMOVE ITEM 3 SCREW TO
DETACH ITEM 5 SENSOR

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
