SATO E series Service Manual

PN 9001098
Rev. A
6-1
SATO M-10e TT/DT Printers Service Manual
Replacement Procedures
6.1 Overview
The SATO M-10e Printer contains replaceable components and subassemblies. This section
contains step-by-step instructions for removing and replacing the following components and
sub-assemblies.
• Print Head
• Timing Belt
• Platen Roller
• Feed Roller
• LC /Keyboard PCB
• Main Circuit Board
• Interface PCB
• Power Supply
• Stepper Motor
• Fuses
• EEPROM
• Ribbon PCB
• Pitch Sensors
• Label Penetrating Sensor
• Ribbon Sensor
•Cutter Unit
Procedures in this section require standard metric tools.
Other equipment is listed where required.
Section
6

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
