SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
10-4
Section 10. Spare Parts List
Side Frame RH Assembly
NO. CODE DESCRIPTION QTY
1 PA6A60002 SIDE FRAME(R) 1
2 MD4300622 PAN HEAD SCREW 3
4 PT9A60000 PCB SPACER 1
6 PA3A60001 BRACKET 1
7 PE3720100 TENSION ROLLER 1
8 PB0740900 SHAFT(TENSION ROLLER) 1
9 ND0040030 E-SNAP RING 2
10 MD4300622 PAN HEAD SCREW 2
12 PC0A60101 SPRING(TENSION ROLLER) 1
14 PU3400060 TIMING BELT(S2M*400) 1
16 P00228010 HEAD STOPPER 1
17 MD4300622 PAN HEAD SCREW 1
24 KB200371A STEPPER MOTOR 1
25 RH1A61700 STEPPER MOTOR CABLE 1
26 PR1A60500 PULLEY 1
27 MJ1400524 W-POINT SET SCREW 2
28 MD3401022 PAN HEAD SCREW 4
30 MT1300522 HEX NUT 1
31 PB0A60100 SHAFT(TOP FRAME) 1
32 PA3A60200 RIBBON BRACKET(RL) 1
33 MD0300422 PAN HEAD SCREW 2
35 PA1A60100 SUPPORTER CLAMP(B) 1
36 MJ9300322 THIN HEAD SCREW 2
38 PA3A60800 PLATE(ESCAPE) 1
39 PC2A60000 SPRING(FEED ROLLER) 1
40 PB0A60202 SHAFT(SPRING) 1
41 P00669000 SPRING (FEED ROLLER) 1
42 MD4301422 PAN HEAD SCREW 1

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
