SATO M-10e TT/DT Printers Service Manual
Section 10. Spare Parts List
Cutter Assembly (Option)
NO. CODE DESCRIPTION QTY
1 PK1A60010 CUTTER UNIT 1
2 P00751000 CUTTER BRACKET(A)SET 1
3 MD4300622 PAN HEAD SCREW 4
5 P00761000 CUTTER GUIDE(D) 1
6 MD4300622 PAN HEAD SCREW 3
8 RH1A61901
CUTTER SENSOR CABLE ASSY
1
9 MD4231022 PAN HEAD SCREW 1
11 R01059000 CUTTER BRACKET(C) 1
12 MD4300622 PAN HEAD SCREW 3
13 P00748000 CUTTER GUIDE TOP(D) 1
14 MD4300622 PAN HEAD SCREW 3
15 PB9A60200 GUIDE SCREW 2
16 P00749000 CT GUIDE SHEET B 1
19 MD4401022 PAN HEAD SCREW 3
21 RH1A62001
CUTTER SWITCH CABLE ASSY
1
22 MH0231022 P TIGHT SCREW 1

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
