SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
10-2
Section 10. Spare Parts List
Bottom Assembly
NO CODE DESCRIPTION QTY
1 PA5A60010 BOTTOM PLATE 1
2 PT6680100 RUBBER FOOT 4
4 K00023000 POWER SUPPLY 1
5 RH1A60200 POW1 CORD SET 1
6 RH1A60300 POW2 CORD SET 1
7 MD4300622 PAN HEAD SCREW 7
9 RH1A60010 AC CORD SET 1
10 MD3300822 PAN HEAD SCREW 2
12 MD0400622 PAN HEAD SCREW 2
13 NB2040022 LOCK WASHER 2
15 P03036000 COVER 1

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
