SATO E series Service Manual

PN 9001098
Rev. A
5-1
SATO M-10e TT/DT Printers Service Manual
Section
5
Mechanical Adjustments
5.1 Overview
The SATO M-10e Printer contains adjustable sub-assemblies. This means that during your
regular maintenance, your service technicians are able to make adjustments to reset the
printer to factory specifications thereby ensuring optimim performance of your printer.
The main mechanical sub-assemblies are:
• Drive Belt Assembly
• Print Head Assembly
In this section you will find procedures for:
• Timing Belt Adjustment
• Head Facing Adjustment
• Print Head Front and Rear Alignment
• Ribbon Tension Adjustment
Checks and adjustments in this section require standard metric tools.
Other equipment is listed where required.

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
