PN 9001098
Rev. A
10-37
SATO M-10e TT/DT Printers Service Manual
Section 10. Spare Parts List
Stacker Assembly (Option)
NO. CODE. DESCRIPTION QTY
1 P00190000 BASE FRAME 1
2 P00222000 RUBBER FOOT 4
3 MA0300622 PAN HEAD SCREW 4
4 P00185000 CENTER FRAME 1
5 MA2300622 BIND SCREW 8
6 P00283000 ST.GUIDE SET 1
7 MA0300622 PAN HEAD SCREW 2
8 NB0030022 WASHER 2
9 P00191000 GUIDE BRACKET 2
10 MA1300622 SCREW 4
11 NA1030022 WASHER 4
12 MT1300522 HEX NUT 4
13 P00184000 COLLAR 2
14 MA7300522 SCREW 2
15 P00186000 SLIDE(POST) 2
16 P00187000 COLLAR 2
17 NA0040022 WASHER 2
18 PC1A10200 SPRING(BELT) 2
19 MD4301022 PAN HEAD SCREW 2
20 P00906000 POLY SLIDER 2
