SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
10-10
Section 10. Spare Parts List
Frame C Assembly
NO. CODE DESCRIPTION QTY
1 PR4A60001 FRAME(C) 1
2 MD4300622 PAN HEAD SCREW 6
4 PR3A60002 RACK PLATE(R) 1
5 PA3A61301 GUIDE PLATE(R) 1
7 PT9A60200 HAND SCREW 2
8 PE2750400 GUIDE COLLAR(STACKER) 2
9 MC0301622 PAN HEAD SCREW 2
10 MT1300522 HEX NUT 2
11 PA1A60000 NUT PLATE 2
13 PR3A60102 RACK PLATE(L) 1
14 PR3A60510 GUIDE PLATE(L) 1
16 RJ1A60300 CABLE SENSOR (TOP) 1
17 PE6A60001 COVER (SENSOR) 1
18 MD3300522 PAN HEAD SCREW 1
20 RH1A61001 SEN CABLE ASSY 1
22 PA3A61100 SENSOR BRACKET 1
23 MA1300422 FLAT SCREW 2
25 PA3A61000 SENSOR BRACKET (B) 1
26 MD4300622 PAN HEAD SCREW 1
28 RJ1A60400 AUTO LOAD SENSOR 1
29 MD4300422 PAN HEAD SCREW 1
31 PE8A60010 PLATE(RACK) 2
32 P00585010 COLLAR 4
33 PA3A61700 SENSOR BRACKET (F) 1
34 RJ1A60203 LABEL SENSOR (BOTTOM) 1
35 MD4300422 PAN HEAD SCREW 1
37 PE8500200 GEAR 1
38 P00619000 COLLAR 1
39 MD4300622 PAN HEAD SCREW 1
41 PR3A60201 GUIDE PLATE(BOTTOM) 1
43 PA3A61800 GUIDE PLATE(RACK) 1
45 NA1030022 WASHER 2
46 NB0030022 WASHER 6
47 MT1300522 HEX NUT 6
48 NA1030022 WASHER 2
50 NA1030022 WASHER 4

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
