SATO E series Service Manual

PN 9001098
Rev. A
10-15
SATO M-10e TT/DT Printers Service Manual
Section 10. Spare Parts List
Head Lock Assembly
NO. CODE NAME QTY
1 PR3A60300 HEAD LOCK SHAFT 1
2 ND0060030 E-SNAP RING 1
4 PR3A60401 HEAD LOCK LEVER 1
5 MJ1400524 W-POINT SET 2
7 PE6A60400 COVER(HEAD LOCK LEVER) 1
8 MH0250621 P-TIGHT SCREW 3
10 PC0A60000 HEAD LOCK SPRING 1

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
