SATO E series Service Manual

PN 9001098
Rev. A
10-21
SATO M-10e TT/DT Printers Service Manual
Section 10. Spare Parts List
Head Assembly
ITEM CODE DESCRIPTION QTY
31 PE6A60600 HANDLE 1
32 PR4A60701 HANDLE 1
33 MD4300622 PAN HEAD SCREW 4
35 PA3A63101 HEAD FRAME 1
36 PA3A63200 HEAD OPEN SWITCH BRACKET 1
37 MD4300622 PAN HEAD SCREW 1
38 RH1A60501 HEAD OPEN SWITCH ASSY 1
39 MD0231022 PAN HEAD SCREW 1
41 PA3A63300 HEAD ADJUST PLATE 1
42 PB5A60000 POST(ECCENTRIC) 1
43 ND0030030 E-SNAP RING 1
45 PR1A60110 ADJUST PLATE(HEAD) 1
46 MD4301022 PAN HEAD SCREW 2
48 PR7A60101 THERMAL HEAD 1
49 P02551000 POST(HEAD) 1
51 RH1A60401 HDP CORD SET 1
52 RH1A60610 HDS CORD SET 1
54 MD4300822 PAN HEAD SCREW 2
55 NA1030022 WASHER 2

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
