Section 10. Spare Parts List
Head Assembly
NO. NO. NAME QTY
1 PA3A62701 TOP FRAME 1
2 MD4300622 PAN HEAD SCREW 2
4 PA3A62800 HEAD CLOSE BRACKET 2
5 PB0A60800 HEAD LOCK STUD 2
6 ND0025030 E-SNAP RING 2
7 MD0300422 PAN HEAD SCREW 2
9 PA3A63000 CONVERT PLATE 1
10 PT9A60300 ANTI STATIC BRUSH 1
11 PL2720100 ADJUST COLLAR 2
12 MD4300822 PAN HEAD SCREW 2
14 PB0A60900 CONVERT SHAFT 1
15 MA0300622 PAN HEAD SCREW 2
16 PR7A60200 SHAFT(RIBBON) 1
18 PT2A60100 BEAR FIGHT 2
19 ND0030030 E-SNAP RING 1
21 P03038000 CABLE GUIDE 1
22 MD4300622 PAN HEAD SCREW 1
24 PC1A60000 HEAD SPRING 4
26 PB0A61001 HEAD ADJUST SHAFT 1
27 PB5A60100 HEAD ADJUST CAM 2
28 MA0301422 PAN HEAD SCREW 2
29 ND0050030 E-SNAP RING 4

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
