SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
7-4
Section 7. Factory Resets
7.4 Clear Cutter Counters
To reset the printer to the factory settings, perform the following steps.
CAUTION: Resetting the printer will clear the registers.
STEP PROCEDURE
1. Refer to illustrations on page 7-1. Record all current dip switch positions,
then place all switches in the OFF position.
2. Place the DSW2-4 in the ON position.
3. Press the LINE and FEED keys simultaneously while turning on the power.
Release the keys when the printer beeps. The following screen will appear.
4. Place the DSW2-4 in the OFF position and the following screen will appear.
5. Press the ENTER key to display the next screen.
6. Press the key three times to change the message for NONE to CUT.
7. Press the ENTER. After a pause the next screen is displayed.
8. Select the print size by pressing the keys. The default is
LARGE. Start the test print by pressing ENTER.
9. Press the ENTER to stop the printing and ENTER again to resume.
Warning: This test activates all the heating elements on the print head and
therefore should be used only for testing purposes with full width labels to
avoid damaging the print head.
10. Verify that the counters on the test print have reset to 0.0 km.
11. Power OFF the printer and confirm the swiches are in the OFF position.
maintenance mode
dipsw2-4 on>off
factory mode
counter mode
none
counter clear
cut
print size
small large
