SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
10-26
Section 10. Spare Parts List
Ribbon Rewind Assembly
NO. CODE DESCRIPTION QTY
1 PE4A60200 RIBBON BOBBIN 1
2 ND0060030 E-SNAP RING 1
3 PC1A60100 SPRING(BOBBIN) 1
4 PB0A61300 RIBBON SHAFT 1
6 PA3A63600 RIBBON FRAME(R) 1
7 PA2A60300 PLATE(RIBBON ADJUST) 1
8 MD4400822 PAN HEAD SCREW 1
9 MD4300622 PAN HEAD SCREW 2
11 PE6A60101 EDGE COVER 1
12 PT9500200 NYLON RIVET 3
14 MD4300622 PAN HEAD SCREW 2
16 PA3A63900 COVER 1
18 PE4A60000 RIBBON BOBBIN(TORQUE) 1
19 ND0060030 E-SNAP RING 2
20 PB0A61200 RIBBON SHAFT(TORQUE) 1
22 PA3A63700 RIBBON FRAME(L) 1
24 RH1A61801 STEPPER MOTOR 1
25 PE8A60300 PULLEY 1
26 PB0A61401 STUD (RIBBON MOTOR) 3
27 MD4300622 PAN HEAD SCREW 3
29 PU3204060 TIMING BELT 1
31 PT2A60300 BEAR FIGHT 2
32 PE8A60200 PULLEY 1
33 P00005000 TORQUE LIMITER 1
34 NG2201430 PARALLEL PIN 1
35 PE2A60000 ENCODER PLATE 1
37 PA3A63800 RIBBON BRACKET(L) 1
38 MD4300622 PAN HEAD SCREW 2
40 PE6A60201 MOTOR COVER 1
41 MH9300822 P-TIGHT SCREW 2
43 MD4300622 PAN HEAD SCREW 2
45 MD4300622 PAN HEAD SCREW 4

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
