SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 900109
Rev. A
4-16
Section 4. Electrial Checks and Adjustments
Adjustment of Pitch Correction (Part 1 and 2)
MAIN CIRCUIT
BOARD
POTENTIOMETER
VR3 (PITCH)
LINE KEY
FEED KEY
DIRECTION
KEYS
ENTER
KEY
DSW2-4
POTENTIOMETER
VR9 (PITCH)
POTENTIOMETER
VR3 (PITCH)
POTENTIOMETER
VR9 (PITCH)

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
