PN 9001098
Rev. A
4-15
SATO M-10e TT/DT Printers Service Manual
Section 4. Electrical Checks and Adjustments
Adjustment of Pitch Correction (Part 2)
STEP PROCEDURE
Adjustment continues from Part 1
Refer to illustrations on page 4-16.
1. Be sure VR3 (PITCH VR) on the top cover is aligned to the center position.
2. Power on the printer while pressing the FEED key. Release the Feed key after the beep
sound and the printer will display the Test Print Mode message on the LCD panel.
3. Press the ENTER key to display the next screen.
4. Press the LINE/FEED keys to adjust the print size width.
5. Press the ENTER key and perform the user test print. Stop the test print using the ENTER
key.
6. Use the scale of the test print to check for print skew, and then adjust using VR3 (PITCH
VR) on the top cover.
7. Stop the test print using the ENTER key and power OFF the printer.
Make sure the print position is appropriate.
The VR3 (PITCH VR) adjustment range is +/- 3.75mm.
NOTE: If there is no change in the print position when VR3 (PITCH VR) is adjusted,
replace the main circuit board. Refer to Section 6.8.
test print mode
configuration
test print size
26cm
To Next Page
