SATO M-10e TT/DT Printers Service Manual
Section 1. Overview and Specifications
All specifications subject to change without notice.
ACCESSORIES AND OPTIONS
PCMCIA MEMORY
EXPANSION
One slot for PCMCIA Memory Card (up to 4 MB SRAM or 16 MB Flash
ROM). Can be used for graphic file storage, print buffer expansion, format
storage and downloaded fonts.
CALENDAR An internal Date/Time clock that can be used to date/time stamp labels at
the time of printing.
LABEL CUTTER An attachment allowing labels to be cut at specified intervals. Controlled
through programming.
COAX/TWINAX
INTERFACE
Coan/Twinax Plug-In Interface module. Coax interface emmulates an IBM
3287-2 printer with a stndard Type A BNC connector. Twinax interface
emulates IBM 5224, 5225, 5226 or 4214 printers with auto-terminate/cable
through capabilities.
PARALLEL INTERFACE IEEE1284 Bi-Directional Plug-In Interface Module
SERIAL INTERFACE High Speed RS232 Plug-In Interface Module
USB INTERFACE Universal Serial Bus Plug-In Interface Module
ETHERNET INTERFACE 10/100 BaseT Plug-In Interface Module
1.10 Accessories and Options

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
