SATO E series Service Manual

PN 9001098
Rev. A
1-15
SATO M-10e TT/DT Printers Service Manual
Section 1. Overview and Specifications
BAR CODE M10e
SYMBOLOGIES
Linear Bar Codes Bookland (UPC/EAN Supplemental)
EAN-8/EAN-13
CODABAR
CODE 39
CODE 93
CODE 128
Interleaved 2 of 5 (I 2/5)
Industrial 2 of 5
Matrix 2 of 5
MSI
POSTNET
UCC/EAN-128
UPC-A/UPC-E
Two Dimensional Data Matrix
Maxicode
PDF417
Micro PDF
Truncated PDF
QR Code
1:2, 1:3, 2:5, User Programmable
Bar Height 4 to 999 dots, User Programmable
Rotation 0°, 90°, 180° and 270° Rotation
OTHER FEATURES
Sequential Numbering Sequential numbering of both numerics and bar codes
Custom Characters RAM storage for custom designed characters
Graphics Dot addressable, SATO Hex/Binary, BMP or PCX formats
Forms Overlay Overlay of predesigned forms in image buffer
1.8 Bar Codes

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
