SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
1-16
Section 1. Overview and Specifications
SPECIFICATION M10e
PHYSICAL
Wide 18.7 in. (475 mm)
Deep 12.3 in. (313.4 mm)
High 12.6 in.(319.2 mm)
Weight 50.7 lb. (23 kg)
POWER
Input Voltage Autoswiching 100-240 VAC +/-10%, 60 Hz
Power Consumption 560W Operating, 40W Idle
ENVIRONMENTAL
Operating Temperature 41° to 104°F (5° to 40°C)
Storage Temperature (-5° to 60°C)
Storage Humidity 30 to 90% RH Non-Condensing
Operating Humidity 30 to 80% RH Non-Condensing
Electrostatic Discharge
REGULATORY APPROVALS
Safety UL, CSA, TUV
RFI/EMI FCC Class B
1.9 Physical, Power, Environmental & Approvals

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
