SATO E series Service Manual

PN 9001098
Rev. A
10-1
SATO M-10e TT/DT Printers Service Manual
Spare Parts List
10.1 Overview
The following parts lists are included in this section.
Note:
The spare parts information in this manual is accurate at the time
of publication of this service manual and is subject to change
without notice.
Section
10
•Bottom Assembly •Guide Plate Top Assembly
• Side Frame RH Assembly • Head Assembly
• Side Frame LH Assembly • Ribbon Unwind Assembly
• Main PCBA Assembly • Ribbon Rewind Assembly
• Ribbon PCB Assembly • Cover Assembly
• Frame C Assembly • Keyboard Assembly
• Frame E Assembly • Tear Off Cutter Assembly
• Stay Assembly • Cutter Assembly (Option)
• Head Lock Assembly • Unwind Assembly (Option)
• Pressure Roller Assembly • Stacker Assembly (Option)
• Platen Roller Assembly • Interface Board Assembly
• Feed Roller Assembly

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
