SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
1-12
Section 1. Overview and Specifications
SPECIFICATION M10e
PRINT
Method Direct or Thermal Transfer
Speed (User Selectable) 3/4/5 ips
50 to 125 mm/s
Print Module (Dot Size) ..0033 in.
.083 mm
Resolution 309 dpi
12 d/mm
Maximum Print Width 10.5 in.
266 mm
Maximum Print Length 16.5 in.
420 mm
MEDIA
Minimum Width 5.16 in.
131 mm
Minimum Length 1.7 in.
43 mm
Maximum Width 11.8 in.
300 mm
Type Roll or Fan-Fold Die Cut Labels
Thermally Sensitive for M10eDT
Maximum Caliper 0.008 in.
0.21 mm
Roll OD (max) Face-In 7.8 in.
200 mm
Core ID (min) 3 in
76.2 mm
SENSING
See-Thru Fixed, 0.9 in. (22.5 mm) left of center
Reflective Eye-Mark Fixed, 0.2 in. (5 mm) from left label edge
Continuous Form Not Used
RIBBON
Widths 6.5 in. (165 mm), 8.7 in. (220 mm), 10.7 in.(273 mm)
Length (max) 984 ft. (300 m)
Thickness 4.5 micron, Wound Face-In
1.6 General Printer Specifications

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
