SATO M-10e TT/DT Printers Service Manual
Section 1. Overview and Specifications
SPECIFICATION M10e
CONTROLS AND INDICATORS
Power Green LED
On-Line Green LED
Error Red LED
LCD Panel 2 Line x 16 Character
Auto-Load (Rear Panel) Green LED
Power On/Off Switch Front Casework
On/Off-Line Key Front Panel
Feed Switch Key Front Panel
Cursor Control Keys Front Panel
Enter Key Front Panel
POTENTIOMETER ADJUSTMENTS
Print Darkness Top Panel
Offset Top Panel
Pitch Top Panel
Display Top Panel
INTERFACE CONNECTIONS
(1)
Parallel IEEE1284 Standard
Serial RS232C (9600 to 57600 bps) Standard
RS422/485 (9600 to 57600 bps) Optional
Ready/Busy or X-On/X-Off Flow Control
Bi-directional Status
Universal Serial Bus USB Ver. 1.1 Standard
Ethernet 10/100BaseT
PROCESSING
CPU 32 Bit RISC
Flash ROM 4 MB
SDRAM 16 MB
Receive Buffer 2.95 MB
Memory Expansion See Options and Accessories
(1) Only one interface module can be installed in a printer at a time.
General Printer Specifications

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
