SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
10-6
Section 10. Spare Parts List
Side Frame LH Assembly
NO. CODE DESCRIPTION QTY
1 P00271000 SIDE FRAME(L) 1
2 MD4300622 PAN HEAD SCREW 3
4 PA3A60400 PCB BRACKET(BOTTOM) 1
5 MD4300422 PAN HEAD SCREW 3
7 PA3A60500 PCB BRACKET(TOP) 1
8 MD0300422 PAN HEAD SCREW 2
10 PB0A62101 POST(COVER) 1
11 MD4300622 PAN HEAD SCREW 1
19 P03042000 RIBBON SHAFT(FF) 1
20 MD4401022 PAN HEAD SCREW 1
21 ND0060030 E-SNAP RING 1
22 PT9A60100 ONE WAY HINGE 1
24 PA1A60100 SUPPORTER CLAMP(B) 1
25 MJ9300322 THIN HEAD SCREW 2
31 PA3A60300 PLATE 1
32 PC2A60100 SPRING(FEED ROLLER)L 1
33 PB0A60202 SHAFT(SPRING) 1
34 P00669000 SPRING (FEED ROLLER) 1
35 MD4301422 PAN HEAD SCREW 1

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
