SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
10-28
Section 10. Spare Parts List
Cover Assembly
NO. CODE DESCRIPTION QTY
1 R01457000 REAR COVER SET 1
2 MA2300622 BIND SCREW 3
3 PE6771001 MEMORY CARD COVER 1
4 PB5A20001 HEAD SCREW 1
6 RH1A61601 LED CABLE ASSY 1
8 PH1A60100 SIDE COVER(R) 1
9 MA2300622 BIND SCREW 4
11 R01442000 SIDE COVER(L)SET 1
12 PE6A60300 COVER(DSW) 1
13 MA2300622 BIND SCREW 4
15 R01114000 FRONT COVER 1
16 PZ0A60300 KEY TOP 1
18 RH1A60100
POWER SWITCH CABLE ASSY
1
19 MA2300622 BIND SCREW 2
21 PH0A60100 CUTTER COVER 1
23 PH1A60300 TOP COVER(T) 1
24 PH1A60400 TOP COVER(D) 1
26 PA3A64800 HINGE PLATE(L) 1
27 PA3A64900 HINGE PLATE(R) 1
28 MA2300622 BIND SCREW 16
31 PB0A61500 RELEASE SHAFT 1
32 PC1A60201 SPRING 1
33 ND0030030 E-SNAP RING 1
35 PE6A21900 MICRO DRIVER 1
36 JG100551A CK CLAMP 1

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
