SATO M-10e TT/DT Printers Service Manual
Section 2. Configuration
MODE KEY SEQUENCE INITIAL DISPLAY PAGE
Normal POWER ONLINE
QTY:000000
2-10
Conventional/
Interchangeable
DSW2-8 ON + POWER ONLINE
QTY:000000
Advanced LINE + POWER ADVANCED MODE 2-13
Test Print FEED + POWER TEST PRINT MODE
CONFIGURATION
2-34
Default Setting LINE + FEED + POWER DEFAULT SETTING
YES NO
2-35
Maintenance LINE + FEED + DSW2-4 ON +
POWER
MAINTENANCE MODE
DSW2-4 ON>OFF
2-36
Non Standard Clear LINE + FEED + DSW2-7 ON +
POWER
ALTPROTOCOL 2-38
Protocol Code
Download
LINE + DSW2-7 ON +
POWER
USERDOWNLOAD 2-39
Hex Dump DSW2-4 ON + POWER ONLINE
QTY:000000
2-40
Firmware
Download
DSW2-6 ON + POWER FLASH DOWNLOAD
READY
2-41
2.3 LCD Panel Configuration
The LCD Panel is used in conjunction with the LINE and FEED switches to manually
enter printer configuration settings. Many of the settings can also be controlled via
software commands and in the case of conflict between software and control panel
settings, the printer will always use the last valid setting. If you load a label job that
includes software settings and then enter a new setting via the LCD Panel, the manually
set values will be used by the printer. If you set the values manually and then download
a job with software settings, the software settings will be used.
There are 10 modes of operation you can access from the LCD panel. To enter the
desired mode, the KEY SEQUENCE combination listed in the table must be
performed. The initial LCD display message is shown for each mode.
