SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
2-10
Section 2. Configuration
LCD Panel —Normal Mode
When the printer is first powered on, it displays the current ROM version of the printer, then
immediately displays the ONLINE mode.
The LCD Panel will display the ONLINE status on the top line of the display. The bottom
line will contain the label quantity (QTY) status. The message will be changed to OFFLINE
whenever the printer is switched offline by depressing the LINE key. As soon as a print job
is received, the QTY message will indicate the number of labels to be printed. As soon as the
label job begins to print, the display will indicate the number of labels remaining in the print
job that remain to be printed. The user can access the User Settings using the following
procedures.
initializing
rom v0.00.00.00
online
qty: 000000
User Settings
STEP PROCEDURE
1. The printer is first taken offline by pressing the LINE key once.
The display will change to OFFLINE.
2. Press the LINE and FEED keys simultaneously for more than one
second. The printer now displays the first USER mode adjust-
ment, (Print Darkness).
offline
000000
Print Darkness Setting
There are five Darkness (or heat range) settings on the printer. The higher numbers represent
darker settings. The current setting is indicated by a line under one of the range settings.
To change the setting:
STEP PROCEDURE
1. Use the keys to step the underlined cursor to the desired
setting.
1 = Light
2 = Slightly Light
3 = Medium
4 = Slightly Dark
5 = Dark
2. Once the correct setting is underlined, press the ENTER key to
accept the setting and advance to the next adjustment.
print darkness
1 2 3 4 5
To Next Page
