SATO M-10e TT/DT Printers Service Manual
Section 2. Configuration
LCD Panel —Normal Mode
Print Speed Adjustment
There are three speed settings on the printer. 3 is the slowest speed while 5 is the fastest.
Default setting is 4.
To change the setting:
Setting Speed
3 ? ips (xxxmm/s)
4 ? ips (xxxmm/s)
5 5 ips (125mm/s)
STEP PROCEDURE
1. Use the keys to step the underlined cursor to the desired
setting.
2. Once the correct setting is underlined, press the ENTER key to
accept the setting and advance to the next adjustment.
print speed
3 4 5
Pitch Offset Adjustment
The label pitch is the distance from the leading edge (the edge that comes out of the printer
first) of a label and the leading edge of the next label. The leading edge position of the label
can be adjusted relative to the print head +/- 49 mm in increments of 1 mm. Once the
position is set, it can be fine adjusted +/- 3.75 mm using the PITCH potentiometer on the
adjustment panel. The default value is +0.
STEP PROCEDURE
1. The underline cursor will initially be positioned underneath the +
Pitch Direction Setting. Press the LINE key to select the + / - pitch
offset value.
2. Use the and the LINE/FEED keys to step the cursor to
the first digit.
The display will advance one increment each time the LINE key is
pressed to a maximum setting of 5. Once the desired setting is
selected, press the ENTER key to accept the setting and advance to
the second digit. Once again the display will advance one increment
each time the LINE key is pressed.
3. Once the desired setting is selected, press the ENTER to accept the
setting and advance to the
next display.
pitch offset
+/- 00mm
To Next Page
