SATO E series Service Manual

SATO M-10e TT/DT Printers Service Manual
PN 9001098
Rev. A
10-24
Section 10. Spare Parts List
Ribbon Unwind Assembly
NO. CODE DESCRIPTION QTY
1 PE4A60200 RIBBON BOBBIN 1
2 ND0060030 E-SNAP RING 1
4 PE4A60000 RIBBON BOBBIN(TORQUE) 1
5 ND0060030 E-SNAP RING 1
6 PC1A60100 SPRING(BOBBIN) 1
8 PV0A60000 BEAR FIGHT 1
9 PA3A63500 SLACK PLATE(L) 1
10 PT9A60400 TORQUE LIMITTER 1
11 PC2A60201 TORSION SPRING 1
12 PB0A61200 RIBBON SHAFT(TORQUE) 1
13 NG2201430 PARALLEL PIN 1
14 PE2A60000 ENCODER PLATE 1
15 PT2A60300 BEAR FIGHT 1
17 PA3A60200 RIBBON BRACKET 1
18 RJ1A60601 RIBBON SENSOR PCB 1
19 MA2300422 SCREW 1
20 MD0300422 PAN HEAD SCREW 2
22 RH1A61300 RIBBON SENSOR CABLE 1
