Operating instructions Distance measuring device DL100 – CANopen®
CANopen®-interface
114 © SICK AG • Subject to change without notice • 8015416/ZPN2/2017-09-08
10.12.19 Object 6508h Operating Time
Indication of the operating hours as a multiple of 0.1 nm. E.g. 1 h opera-
tion corresponds to 10 * 0.1h Object 6508h corresponds to object 4005h.
4005h is mapped to 6508h.
10.12.20 Object 6509hOsetValue
Bydefault,theosetvalueis0.Iftheobject6003h“Presetvalue”specif-
ics a preset, the object 6509h is automatically updated as follows:
Distance
oset
= Distance
preset
– Distance
mess.
Thenewosetvaluemustbesaved.
10.12.21 Object 650AhModuleIdentication
Informationofmoduleidentication
Subindex Name Description
0h Number of Available Man-
ufacturerOsetValues
Indication of the number of subindices within object 650Ah.
1h ManufacturerOset Containsamanufacturer-specicosetvalue.FortheDL100,itiscurrently0.
2h Manufacturer Minimal
Position Value
Containstheminimumdistancevalue.Dependingondeviceprole,
DL100 – 300 m
3h Manufacturer Maximal
Position Value
Containstheminimumdistancevalue.Dependingondeviceprole,
DL100 – 300 m
Index0containsamanufacturer-specicosetvalue.FortheDL100,this
value is 0. Index 1 contains the minimum distance value. Index 2 of the
maximum distance value.
The following min/max values apply:
• Prole1:–100m/+100m
• Prole2:–200m/+200m
• Prole3:–300m/+300m
10.12.22 Object 650Bh Serial Number
Contains the 8-digit serial number.
