SICK DL100 User Manual

8015416/ZPN2/2017-09-08 • © SICK AG • Subject to change without notice 125
Operating instructions Distance measuring device DL100 – CANopen®
Technical data
14.1 Dimensions
3
34.3
(1.35)
20
(0.79)
34.7
(1.37)
69.4 (2.73)
6.7
(0.26)
6.7
(0.26)
56 (2.20)
30
(1.18)
44.6
(1.76)
15.2
(0.60)
82.5 (3.25)
104.5 (4.11)
119.9 (4.72)
100.2 (3.94)
18.2
(0.72)
69.4 (2.73)
33 (1.30)
64.6 (2.54)
87.6 (3.45)
12 34
1
2
3
44
44
5
6
7
All dimensions in mm (inch)
Fig. 33: Dimensions distance measuring device DL100
1 Optical axis sender
2 Optical axis receiver
3 Device zero point
4 Threaded mounting hole M5
5 LED "Status"
6 Display
7 Operating elements
