Operating instructions Distance measuring device DL100 – CANopen®
Setup and function
4 Setup and function
4.1 Setup
12
34
Fig. 3: Setup "distance measuring device DL100"
1 Threaded mounting hole M5
2 Device zero point
3 Optical axis sender
4 Optical axis receiver
5 Bore for knurled screw of the optional alignment bracket
6 Holder for optional alignment bracket
7 Electrical connection
8 Display and operating unit
