8015416/ZPN2/2017-09-08 • © SICK AG • Subject to change without notice 55
Operating instructions Distance measuring device DL100 – CANopen®
Operation at the measuring device
8.5.13 Menu„Oset“
Setanosetviathismenu.
Youcangettothemenu"Oset"viathemenupath:
Main menu →
→ Menu → → CANopn → → more → →
MFx On → → (MF1 → → MF2 → →)Oset
Push the
key.Thecurrentlysetosetisdisplayedhere.
Requirements for the display
• Menu "more": Option "Yes"
Value Description
Oset Specifyoset.Theosetisaddedtotheinternallydetermined
measurementvalue.Theosetaectsalloutputsandthe
display indication.
Whenthe"Preset"functionisactivated,theosetisover-
written by triggering of the preset input.
Adjustment range
• –300000…+300.000mm
Factory setting
• 0[mm]
Table 21: Menu "Oset"
8.5.14 Menu “SpecFu”
Set special functions via this menu.
You can get to the menu “SpecFu” via the menu path:
Main menu →
→ Menu → → CANopn → → more → →
MFx On → → (MF1 → → MF2 → →)Oset→ → SpecFu
Push the
key so that the parameter “AvgDst” is displayed.
Use the keys
and to browse within the menu.
Requirements for the display
• Menu “more”: Option “Yes”
Parameter Description
AvgDst Selectlterdepthforthedistancevalues.
Options
• Medium
• Slow
• Fast
Factory setting
• Medium
Note: Medium and Fast use the same averaging depth.
