Operating instructions Distance measuring device DL100 – CANopen®
Technical data
128 © SICK AG • Subject to change without notice • 8015416/ZPN2/2017-09-08
14.7 Outputs
Outputs Multifunction outputs MF1 and MF2, type: B (push/pull), adjustable
Hi>UV–3V
Lo < 2 V
See page 48, Table 15 and page 54, Table 20, parameter
ActSta.
Maximum output current Max. 100 mA
Output load Capacity: 100 nF
Inductive 20 mH
Table 82: Outputs
14.8 Interfaces
CANopen
®
Process data interface
Baud rate Depends on cable length
Ethernet Congurationinterface
Table 83: Interfaces
14.9 Ambient conditions
Protection class III
Suitable for operation in PELV systems (Protective Extra Low Voltage -
safety extra-low voltage) with secure separation.
Electromagnetic compatibility
1)
EN 61000-6-2, EN 55011, category A
Ambient temperature range Seetype-specicdata
Storage temperature range –40°C…+75°C
Enclosure rating IP65
Airpressureinuence 0.3 ppm/hPa
Temperatureinuence 1 ppm/K
Temperature drift Typical 0.1 mm/K
Maximum movement speed 10 m/s
Maximum acceleration change 10 m/s²
Vibration resistance (sine) EN 60068-2-6
Noise EN 60068-2-64
Shock resistance EN 60086-2-27
1) When used in the household area, the device may cause interferences.
Table 84: Ambient conditions
