Operating instructions Distance measuring device DL100 – CANopen®
Operation at the measuring device
8.4 Change value
1. Use the keys and to select the desired parameter.
2. Push the key
. The current value of the parameter is displayed. The
rstgureontheleftashes.
3. Push the key
toincreasethegure.Pushthekey to reduce the
gure.
4. Push the key
tosavethegureentered.Thenextgureashes.
Push the key to cancel the process.
5. Repeatthesteps3and4untilthelastgureissaved.Theparameter
name is displayed.
6. Push the key
until the measured value is displayed again. Alterna-
tively, you may also wait for a few minutes. The display automatically
switches back to measured value display without operation of a key.
8.5 Parameter description
8.5.1 Main menu
The measurement value is displayed by default:
Use the
-key to get from the measured value display to the display
"Level Bargraph". Use the keys and to browse within the main
menu.
Push the
-key for at least 2 seconds to get to the “Menu”.
Display Description
Measurement
value
Measurement value display in mm
Level
Bargraph
Level display (damping value) as bargraph
Level numeric Level display (damping value) as numeric value
→ Also see page 32, Table 4.
Temperature Display of indoor temperature of the measuring device
Operating hours
counter
Operating hours display
Warnings Display of the pending warnings. When a warning is pending,
the LED PWRashesorange.Whennowarningsarepending,
no warnings are displayed.
→ Also see page 122, chapter 12.2, list of possible warn-
ings.
Error Display of the pending warnings. When an error is pending, the
LED PWRashesred.Whennoerrorsarepending,noerrors
are displayed.
→ Also see page 122, chapter 12.3, list of possible errors.
Table 9: Main menu
