8.5.9 Submenu „MF1 – Speed“
This submenu is used to parameterize the multifunction output MF1 as
speed output.
You can get to the menu "Speed" via the menu path:
Main menu →
→ Menu → → CANopn → → more → →
MFx On → → MF1 → → ActSta → → Functn → → Speed
Requirements for the display
• Menu "more": Option "Yes”
• Menu "MFx On": Option "Enable"
• Parameter "Functn": Option "Speed"
Parameter Description
Limit Set speed for the switching threshold The switching output is
activated when the current speed exceeds the set speed. The
switchinghysteresisissetrmlyto±0.1m/s.
Adjustment range
Range 0.0 … 9.9 m/s
Factory setting
• 0[mm]
Sign Choose the travel direction to be monitored.
Options
• +/–:Oncethesetspeedisexceededinonedirection,the
switching output is activated.
• +:Oncethesetspeedisexceededwithincreasingdistance,
the switching output is activated.
• –: Once the set speed is exceeded with decreasing distance,
the switching output is activated.
Factory setting
• +/–
Table 17: Submenu "MF1 – Speed"
