SICK DL100 User Manual

Operating instructions Distance measuring device DL100 – CANopen®
Identication
20 © SICK AG • Subject to change without notice • 8015416/ZPN2/2017-09-08
3 Identication
3.1 Type label
The type label is located on the measuring device.
MAC
SN:
DL100-11AA2109
1060392
2013
1109 1234
00:06:77:AC:2E:08
1
2
3
4
5
M
4
1
2
3
4
5
M
3
1
2
3
4
2
1
1
2
3
4
M
1
2
3
6
5
4
7
8
9
Fig. 2: Type Label
1 Type code
→ See page 126, chapter 14.2.
2 Supply voltage, multifunction output current
3 Device number
4 MAC address
5 Serial number
6 Assignment for supply voltage plug, Ethernet and CANopen
®
7 Icon: Distance sensor reector mode
8 Barcode
9 Production year and month
