microScan3 Core – EFI-pro microScan3 Pro – EFI-pro
Configuration and diagnostic interface
Type of interface USB 2.0
Connection type USB 2.0 mini-B (female connector)
Transmission rate ≤ 12 Mbit/s
Length of cable ≤ 5 m
Secure device communication via EFI-pro
Connection type Female connector, M12, 4-pin, D-coding
RPI (requested packet inter‐
val)
5 ms to 1,000 ms (multiple of 5 ms)
Electrical data
T
able 33: Electrical data
microScan3 Core – EFI-pro microScan3 Pro – EFI-pro
Operating data
Protection class III (IEC 61140)
Supply voltage U
V
24 V DC (16.8 V to 30 V DC) (SELV/PELV)
1)
Residual ripple ± 5%
2)
Start-up current at 24 V ≤ 3 A
Current consumption at 24 V
Operation ≤ 0.45 A (typ. 0.3 A)
Sleep mode Typ. 0.29 A
Power consumption
Operation ≤ 11 W (typ. 7.2 W)
Sleep mode Typ. 7 W
Power-up delay ≤ 45 s (typ. 20 s)
1)
The power supply unit must be able to jumper a brief power failure of 20 ms as specified in
IE
C 60204-1. Suitable power supply units are available as accessories from SICK.
2)
The voltage level must not fall below the specified minimum voltage.
Mechanical data
T
able 34: Mechanical data
microScan3 Core – EFI-pro microScan3 Pro – EFI-pro
Dimensions (without system
plu
g, W × H × D)
112 mm × 150.8 mm × 111.1 mm
Weight (including system
plug)
1.45 kg
Housing material Aluminum
Housing color RAL 9005 (black) and RAL 1021 (colza yellow)
Optics cover material Polycarbonate
Optics cover surface Outside with scratch-resistant coating
Ambient data
T
able 35: Ambient data
microScan3 Core – EFI-pro microScan3 Pro – EFI-pro
Enclosure rating
1)
IP 65 (IEC 60529)
Ambient light immunity ≤ 3,000 lx (IEC 61496-3)
TECHNICAL DATA 13
