SICK S300 Series User Manual

12 Technical data
12.1 Data sheet
General details
T
able 34: General details
Minimum Typical Maximum
Type 3 (IEC 614961)
Safety Integrity Level
1)
SIL2 (IEC 61508)
SIL claim limit
1)
SILCL2 (EN 62061)
Category Category 3 (EN ISO 13 8491)
Performance Level
1)
PL d (ISO 13849)
PFHd (T
amb
= 25 °C) (me
an probability of a danger‐
ous failure per hour)
8 × 10
–8
T
M
(mis
sion time) 20 years (ISO 13849)
Laser class Laser class 1 (according to IEC 60825-1
a
s well as CDRH 21 CFR 1040.10 and
1040.11; excluded are deviations due to
Laser Notice No. 50 dated June
24, 2007)
Enclosure rating IP65 (EN 60529)
Protection class S300 Medium Range II (EN 50178)
Protection class S300 Long Range III (EN 50178 and EN 60950)
Ambient operating temperature –10 °C +50 °C
Storage temperature range –25 °C +50 °C
+70 °C
(≤
24 h)
Humidity (taking into account the ambient operat‐
in
g temperature)
IEC 61496-1, section 5.1.2 and 5.4.2
IEC 61496-3, section 5.4.2
Height above sea level during operation 2,300 m
Vibration IEC 614961
IE
C 61496-3
Frequency range 10 Hz 150 Hz
Amplitude 0.35 mm or 5 g
Shock resistance IEC 614961, section 5.1 and 5.4.4
IE
C 61496-3, section 5.4.4
Single shock 15 g, 11 ms
Continuous shock 10 g, 16 ms
Sender Pulsed laser diode
Wavelength 895 nm 905 nm 915 nm
Divergence of collimated beam (full angle) 14 mrad
Pulse duration 5.5 ns
Average output power 3.42 mW
Light spot size on the optics cover 8 mm
Light spot size at 2.0 m scanning range 28 mm
Housing
Material Die-cast aluminum
TECHNICAL DATA 12
8010948/ZA21/2020-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | S300
121
Subject to change without notice

SICK S300 Series Specifications

General

Scanning angle	270 °
Number of monitoring cases	4
Protection class	IP65
Number of scanning planes	1
Angular resolution	0.5°
Interface	RS-422, Ethernet
Supply voltage	24 V DC
Ambient operating temperature	0 °C ... +50 °C
Laser class	1 (IEC 60825-1)
Storage temperature	–25 °C ... +70 °C
Protective field range	0.1 m to 3 m
