14 Spare parts
14.1 System plug
Table 41: Part numbers, system plugs
Type code Equipment Description Part number
SX0B-A0000G One M16 cable gland
and one M12 blind
plu
g on the rear
Without cable 2032807
SX0B-B1105G Pre-assembled, 5 m
length of cable, 11
wires
2032859
SX0B-B1110G Pre-assembled, 10 m
len
gth of cable, 11
wires
2032860
SX0B-B1114G Pre-assembled, 14 m
length of cable, 11
wires
2047875
SX0B-B1120G Pre-assembled, 20 m
len
gth of cable, 11
wires
2032861
SX0B-A0000J One M16 cable gland,
three M12 blind plugs
on the rear as well as
two M12 EMC-compli‐
ant cable glands,
loose
Without cable 2032856
SX0B-B1105J Pre-assembled, 5 m
length of cable, 11
wires
2032857
SX0B-B1110J Pre-assembled, 10 m
len
gth of cable, 11
wires
2032858
SX0B-B1505G One M16 cable gland
and one M12 blind
plug on the rear
Pre-assembled, 5 m
length of cable, 15
wires
2034264
SX0B-B1510G Pre-assembled, 10 m
length of cable, 15
wires
2034265
SX0B-X0000XS06 One M16 cable gland,
3 M12 cable glands,
bottom
Pre-assembled with
connecting cables and
plug connectors:
1 × male connec‐
tor, M12, 4-pin, A-
coded, for incre‐
mental encoder
1 × male connec‐
tor, M12, 4-pin, B-
coded, for incre‐
mental encoder
1 × male connec‐
tor, M12, 4-pin, D-
coded, for EFI and
voltage supply
1 × female connec‐
tor, D-Sub, for
measurement data
output
2100518
SPARE PARTS 14
8010948/ZA21/2020-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | S300
137
Subject to change without notice

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SICK S300 Series and is the answer not in the manual?

SICK S300 Series Specifications

General IconGeneral
Scanning angle270 °
Number of monitoring cases4
Protection classIP65
Number of scanning planes1
Angular resolution0.5°
InterfaceRS-422, Ethernet
Supply voltage24 V DC
Ambient operating temperature0 °C ... +50 °C
Laser class1 (IEC 60825-1)
Storage temperature–25 °C ... +70 °C
Protective field range0.1 m to 3 m
