SICK S300 Series User Manual

S300 Professional in conjunction with UE10-3OS; Operating mode: without restart
int
erlock, with external device monitoring; Static monitoring case switching by the con‐
trol input C; Dynamic monitoring case switching by the incremental encoders A and B.
Monitoring case switching between two safety laser scanners with static inputs
S300 Expert
1
15
19
7
9
22
18
13
4
2
5
6
20
8
10
21
17
14
3
FE
S300 Expert
1
6
20
10
21
22
18
14
3
FE
5
19
7
8
9
17
13
4
2
K1 K2 H8.1 H2.1
H2.2
H8.2K3 K4
k3
k4
k1
k2
C1
+24 V
FE
0 V
C2 A1 A2 B1 B2
1)
k2k1
x1
x1
y1
y1
k4k3
x2
x2
y2
y2
k4
k3
z2
z2
k2
k1
z1
z1
E112699/00/2014-03-06
Figure 43: Connection diagram for monitoring case switching between two safety laser scanners
w
ith static inputs
S300 Expert and S300 Expert in an EFI system in conjunction with relays (contactors);
Operating mode: without restart interlock, with external device monitoring; Static moni‐
toring case switching by the control inputs A, B and C. The protective fields affect the
respective OSSDs on the host and guest.
4 P
ROJECT PLANNING
54
O P E R A T I N G I N S T R U C T I O N S | S300 8010948/ZA21/2020-06-18 | SICK
Subject to change without notice

SICK S300 Series Specifications

General

Scanning angle	270 °
Number of monitoring cases	4
Protection class	IP65
Number of scanning planes	1
Angular resolution	0.5°
Interface	RS-422, Ethernet
Supply voltage	24 V DC
Ambient operating temperature	0 °C ... +50 °C
Laser class	1 (IEC 60825-1)
Storage temperature	–25 °C ... +70 °C
Protective field range	0.1 m to 3 m
