SICK S300 Series User Manual

15 Accessories
15.1 Connectivity
Service cables
T
able 42: Ordering information, service cables
Part Description Part number
Service cable, 2 m For connecting the configuration connection to
t
he serial interface on the PC
M8 × 4-pin to DSub 9-pin, approx. 2 m
6021195
Service cable, 10 m For connecting the configuration connection to
t
he serial interface on the PC
M8 × 4-pin to DSub 9-pin, approx. 10 m
2027649
USB Service cable, 2 m For connecting the configuration connection to
t
he USB interface on the PC
M8 × 4-pin to USB-A male connector, approx.
2 m
6034574
USB Service cable, 10 m For connecting the configuration connection to
t
he USB interface on the PC
M8 × 4-pin to USB-A male connector, approx.
10 m
6034575
RS-232 to USB adapter USB-A male connector to D-Sub male connec‐
t
or, 9-pin
6035396
Connecting cables for self-assembly
Table 43: Connecting cable ordering information
Part Part number
15-wire, cross-section 0.56 mm² (AWG 20), sold by the meter 6030795
EFI cable, sold by the meter (1 × 2 × 0.22 mm²
2
) 6029448
EMC-compliant M12 cable gland for EFI connections, permissible cable
diameter 3–6.5 mm
5308757
DeviceNet connecting cable, PVC, cable diameter 12.2 mm, sold by the
meter
6030756
DeviceNet connecting cable, PVC, cable diameter 6.9 mm, sold by the meter 6030921
Interconnectron male connector, can be used for DeviceNet connecting
c
able 6.9 mm (6030921).
6024742
15.2 Brackets
Table 44: Ordering information, mounting kits
Mounting kit Description Part number
1a Mounting bracket for direct mounting at the
r
ear on the wall or machine
2034324
1b Mounting bracket for direct mounting at the
r
ear on the wall or machine, with optics cover
protection
2034325
2 Mounting bracket only in conjunction with
mounting brackets 1a or 1b, lateral axis
adjustment possible
2039302
3 Holding plate only in conjunction with mount‐
ing bracket 2, longitudinal axis adjustment
possible
2039303
15 ACCESSORIES
138
O P E R A T I N G I N S T R U C T I O N S | S300 8010948/ZA21/2020-06-18 | SICK
Subject to change without notice

SICK S300 Series Specifications

General

Scanning angle	270 °
Number of monitoring cases	4
Protection class	IP65
Number of scanning planes	1
Angular resolution	0.5°
Interface	RS-422, Ethernet
Supply voltage	24 V DC
Ambient operating temperature	0 °C ... +50 °C
Laser class	1 (IEC 60825-1)
Storage temperature	–25 °C ... +70 °C
Protective field range	0.1 m to 3 m
