Minimum Typical Maximum
At 1 σ ± 28 mm
At 2 σ ± 36 mm
At 3 σ ± 44 mm
At 4 σ ± 52 mm
At 5 σ ± 60 mm
Measurement error on data output via RS-422 (S300 Long Range up to 3 m in the specified
r
adiance factor range)
Systematic error ± 20 mm
Statistical including systematic error
At 1 σ ± 29 mm
At 2 σ ± 38 mm
At 3 σ ± 47 mm
At 4 σ ± 56 mm
At 5 σ ± 65 mm
Flatness of the scan field at 2 m ± 50 mm
Distance of mirror rotational axis (zero point of X-
and Y
-axis) to rear side of device
55 mm
Distance between center point of scan plane and
bottom edge of the housing
116 mm
Warning field
2)
8 m
Distance measurement range 30 m
Number of multiple samplings (can be configured
v
ia CDS)
2 16
Power-up delay
Configured device 15 s
When the configuration is read out of the system
plu
g
25 s
Restart after (can be configured) 2 s 60 s
Basic response time 80 ms
1)
Complies with Diamond Grade 3000X™ (approx. 1,250 cd/lx × m²).
2)
The detection capability of the warning field depends on the radiance factor of the objects to be detected
(see "Char
acteristic curves", page 128).
Electric
T
able 36: Electric
Minimum Typical Maximum
Supply voltage (SELV)
1)
2)
16.8 V 24 V 30 V
Permissible residual ripple
3)
± 5%
Start-up current
4)
2 A
Operating current without output load
5)
0.25 A 0.33 A
Operating current with maximum output load
5)
1.7 A
Power consumption without output load
5)
6 W 8 W
Power consumption with maximum output load
5)
41 W
Power consumption in standby mode or park mode
w
ithout output load
5)
6 W 8 W
Electrical connection System plug with screw connections
TECHNICAL DATA 12
8010948/ZA21/2020-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | S300
123
Subject to change without notice
