SICK S300 Series User Manual

When switching on the safety laser scanner in an EFI system, the following message
appe
ars briefly on the 7-segment display:
•
 at the host
•
 at the guest
NOTE
In an E
FI system with an S3000, the S300 must be configured as the guest. It must not
be configured as the host.
3.2.8.1 Interoperability of variants
In the course of further developing the safety laser scanner, additional functionality
suc
h as the triple field technology has been implemented in the devices. The latest
devices are therefore not fully compatible with the safety laser scanners already in the
field.
To ensure the compatibility of the devices, S300 safety laser scanners with
firmware ≥ 02.10 and serial number > 12210000 can be operated in compatibility
mode. The following tables show which devices can form an EFI system.
Interoperability with safety laser scanners
T
able 3: Interoperability with safety laser scanners
S3000 Standard S3000 Advanced S3000 Professional S3000 Remote S3000 Expert S300 Standard S300 Advanced S300 Professional S300 Expert S300 Mini Standard
1)
S300 Mini Remote
S300 Standard
l l l l l l l l l
–
l
S300 Advanced
l l l l l l l l l
–
l
S300 Professional
l l l l l l l l l
–
l
S300 Expert
l l l l l l l l l
–
l
1)
This device does not have an EFI interface so it cannot be used in an EFI system.
l = E
FI system supported
– = EFI system not supported
Interoperability with safety laser scanners in compatibility mode
T
able 4: Interoperability with safety laser scanners in compatibility mode
S3000 Standard S3000 Advanced S3000 Professional S3000 Professional CMS S3000 Remote S3000 Expert S300 Standard
1)
S300 Advanced S300 Professional S300 Professional CMS S300 Expert S300 Expert CMS S300 Mini Standard
1)
S300 Mini Remote
S300 Standard – – – – – – – – – – – – – –
S300 Advanced
l l l l l l
–
l l l l l
– –
S300 Professional
l l l l l l
–
l l l l l
– –
3 PRODUCT DESCRIPTION
22
O P E R A T I N G I N S T R U C T I O N S | S300 8010948/ZA21/2020-06-18 | SICK
Subject to change without notice

SICK S300 Series Specifications

General

Scanning angle	270 °
Number of monitoring cases	4
Protection class	IP65
Number of scanning planes	1
Angular resolution	0.5°
Interface	RS-422, Ethernet
Supply voltage	24 V DC
Ambient operating temperature	0 °C ... +50 °C
Laser class	1 (IEC 60825-1)
Storage temperature	–25 °C ... +70 °C
Protective field range	0.1 m to 3 m
