SICK S300 Series

≥ 3°
Figure 16: Mounting opposite
≥ 100 mm
Figure 17: Mounting offset parallel
≥ 3°
Figure 18: Mounting crosswise
≥ 100 mm
Figure 19: Mounting upside down, offset parallel
4 P
ROJECT PLANNING
