Figure 12: Hazardous point protection: hand detection
Access protection
In ac
cess protection, people are detected if their whole body passes through the protec‐
tive field. This type of protective device is used for the protection of access to haz‐
ardous areas. A stop signal is initiated if the hazardous area is entered. A person stand‐
ing behind the protective device will not be detected by the ESPE.
PRODUCT DESCRIPTION 3
8010948/ZA21/2020-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | S300
25
Subject to change without notice

SICK S300 Series Specifications

General

Scanning angle	270 °
Number of monitoring cases	4
Protection class	IP65
Number of scanning planes	1
Angular resolution	0.5°
Interface	RS-422, Ethernet
Supply voltage	24 V DC
Ambient operating temperature	0 °C ... +50 °C
Laser class	1 (IEC 60825-1)
Storage temperature	–25 °C ... +70 °C
Protective field range	0.1 m to 3 m
