Static 1-of-n sampling
W
ith 1-of-n sampling, you use the single connections of the control input pairs. In this
way, the S300 Advanced provides four input connections.
With 1-of-n sampling, you use the single connections of the control input pairs. In this
way, the S300 Professional provides six input connections.
With 1-of-n sampling, you use the single connections of the control input pairs. In this
way, the S300 Expert provides six input connections.
NOTE
Usin
g external inputs (e.g., those of a Flexi Soft safety controller), a maximum of
ten input connections can be used.
All connections must be connected.
Once connection must be 1.
Only one connection is ever allowed to be 1.
Table 25: Truth table for 1-of-n sampling
A1 A2 B1 B2 C1 C2 D1 D2 E1 E2 E.g.
case
1 0 0 0 0 0 0 0 0 0 1
0 1 0 0 0 0 0 0 0 0 2
0 0 1 0 0 0 0 0 0 0 3
0 0 0 1 0 0 0 0 0 0 4
0 0 0 0 1 0 0 0 0 0 5
0 0 0 0 0 1 0 0 0 0 6
0 0 0 0 0 0 1 0 0 0 7
0 0 0 0 0 0 0 1 0 0 8
0 0 0 0 0 0 0 0 1 0 9
0 0 0 0 0 0 0 0 0 1 10
1 1 0 0 0 0 0 0 0 0 Error
0 0 0 1 1 0 0 0 0 0 Error
0 0 0 0 0 0 0 0 0 0 Error
And all other combinations Error
Further topics
"In
puts", page 81
7 C
ONFIGURATION
96
O P E R A T I N G I N S T R U C T I O N S | S300 8010948/ZA21/2020-06-18 | SICK
Subject to change without notice
