Minimum Typical Maximum
Color RAL 1021 (colza yellow)
Optics cover
Material Polycarbonate
Interface Outside with scratch-resistant coating
System plug ESD-protected
Material Die-cast aluminum
Color RAL 9005 (black)
Device dimensions
2)
Height 152 mm
Width 102 mm
Depth 105 mm
Total weight (without connecting cables) 1.2 kg
1)
For detailed information on the safety configuration of the machine/system, please consult your SICK
sub
sidiary.
2)
Without fixing screws and overrun of cable glands with a mounted system plug.
Functional information
T
able 35: Functional information
Minimum Typical Maximum
Resolution of the S300 Medium Range 30 mm, 40 mm, 50 mm, 70 mm
Protective field of the S300 Medium Range
At 30 mm resolution 1.25 m
At 40 mm resolution 1.60 m
At 50 mm resolution 2.00 m
At 70 mm resolution 2.00 m
Resolution of the S300 Long Range 30 mm, 40 mm, 50 mm, 70 mm,
150 mm
Protective field of the S300 Long Range
At 30 mm resolution 1.25 m
At 40 mm resolution 1.60 m
At 50 mm resolution 2.10 m
At 70 mm resolution 3.00 m
At 150 mm resolution 3.00 m
Scanning angle 270°
Radiance factor 1.8% Several
1,000%
(r
eflectors
1)
)
Angular resolution 0.5°
Generally necessary protective field supplement 100 mm
Supplement for retro-reflectors on scan plane with
distance of less than 1 m to protective field bound‐
ary
200 mm
Measurement error on data output via RS-422 (S300 Medium Range up to 2 m in the specified
r
adiance factor range)
Systematic error ± 20 mm
Statistical including systematic error
12 TECHNICAL DATA
122
O P E R A T I N G I N S T R U C T I O N S | S300 8010948/ZA21/2020-06-18 | SICK
Subject to change without notice
