SICK S300 Series User Manual

Dimensional drawings
73
4
DIN74-F5
110,2
37,9
21,9
16
15,9
49
15,7
74,7
Figure 83: Dimensional drawing mounting kit 1a (mm)
Ø 100
48
4
109,6
110,2
102,5
78
21,9
16
15,9
49
15,7
74,7
73
DIN74-F5
Figure 84: Dimensional drawing mounting kit 1b (mm)
139,4
130
37,7
33,4
18
18
19,7
19,7
118,5
40,7
78,2
4
Figure 85: Dimensional drawing mounting kit 2 (mm)
ACCESSORIES 15
8010948/ZA21/2020-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | S300
139
Subject to change without notice

SICK S300 Series Specifications

General

Scanning angle	270 °
Number of monitoring cases	4
Protection class	IP65
Number of scanning planes	1
Angular resolution	0.5°
Interface	RS-422, Ethernet
Supply voltage	24 V DC
Ambient operating temperature	0 °C ... +50 °C
Laser class	1 (IEC 60825-1)
Storage temperature	–25 °C ... +70 °C
Protective field range	0.1 m to 3 m
