NCK start-up
10.2 System data
CNC Part 1 (NCK, PLC, drive)
Commissioning Manual, 11/2006, 6FC5397-2AP10-2BA0
113
Note
The current, minimum and maximum utilization of the NCK is displayed.
In order to have sufficient reserves for program processing, maximum utilization in reset
condition when pressing the <Reset> key should be in the range of 60-65%.
• Line "Capacity of interpolator buffer":
The capacity indicator MD28060 NUM_IPO_Buffer_SIZE is indicated in %.
This display indicates whether batch preparation for batch processing can commence.
A jerky processing in track control, if for instance a number of short traversing sets have
been programmed in succession, is a typical indicator of the IPO buffers becoming full.
Capacity indication is channel-specific.
